FSWP Hammer Mill Hammer-Shape Pulverizer
SFSP66 series hammer-chip micro mill can crush all kinds of granular feed raw materials, such as corn, sorghum, wheat, crushed cake and other materials.Widely used in various large and medium-sized livestock and aquatic feed factory, wine factory, lemon factory, food factory, grease factory granule raw materials crushing.
HAMMER MILL has drop shape crushing chamber and is highly efficient and energy saving. Hammer mill has hammer arrangement. We can adjust hammer sieve interval to meet the requirement of coarse and fine crushing.
High-precision dynamic balance precision measure ensures stable running and low noise.
The rotor with forward and reverse working prolongs the service life of the quick-wear part. Portable operation door and coordinated type screen press structure makes the operation much safer and more convenient.
Hammer mill can be equipped with frequency conversion impeller-type or belt-type feeder, which makes the working more reliable.
Main Parameter
|
Model |
speed of mainshaft（r/min） |
Power（kw） |
Number of hammer（pcs） |
Weight（kg） |
|
FSWP66*80 |
2970 |
90/110 |
96 |
2500～3000 |
|
FSWP66*100 |
2970 |
132/160 |
128 |
3400～3500 |
